Calibre UK 30W User Manual
Page 2
Technical Information
Panel Specification:
Viewable image size 29.53" (75cm) nominal.
Panel resolution 1280x768.
Colour depth - 8 bits per colour, 24-bits total.
Viewing angles - 85 deg L/R/D/U typical
Panel brightness - 600cd/m
2
typical.
Panel contrast ratio 600:1 typical.
Signal compatibility:
Input 1 – computer RGB via 15HDD socket.
640x350 up to 1280x1024, 50-75Hz refresh,
non-interlaced. (Note: 1280x1024 support is via
image downscaling to fit the 1280x768
resolution panel. There may be a slight loss of
image quality in downscale mode.)
Syncs: separate TTL/5V positive or negative,
negative combined sync TTL level, or negative
sync on green consisting of 0.3V sync and 0.7V
video.
Input 2 – composite video via BNC
PAL, NTSC or SECAM, automatic standards
detection. Pro Video model has automatic
enhanced-bandwidth monochrome mode.
Input 3 – YC/S-Video via 4-pin Mini-DIN
PAL, NTSC or SECAM, automatic standards
detection.
Input 4 – Pro Video Option Only
RGB or YUV component video via 3 or 4 BNCs.
Input 5 – Pro Video with SDI Option Only
SDI Serial Digital Video via BNC.
Input 6 – DVI Option Only
DVI Digital Visual Interface, DDC2B compatible
for connection to DVI compatible graphics cards.
Size and Weight - Cased Models:
720mmx466mmx113mm
13Kg approx including front window
Power requirement:
Cased model: 24VDC 160W max, includes
external 110-230VAC 50-60Hz mains PSU.
Chassis units require mains wiring to screw-
terminals on power supply by suitably qualified
electrical service personnel.
Alternative power option available to special
order: include 115V 400Hz AC aerospace grade
PSU.
Model numbers:
75WXLCD26 xx I zz
I I
| |-M3 = industrial metal case
| |-SC = open chassis
I
I-01 = VGA analogue only
I-02 = VGA analogue + DVI
I-03 = VGA analogue & Std Video
|-04 = 03 + DVI
|-05 = VGA analogue & Pro Video
|-06 = 05 + DVI
|-09 = 05 + SDI Video
|-10 = 05 + DVI + SDI Video
|-11 = Standard video only
|-13 = Professional video only
|-14 = Pro Video + SDI
Note - Front Viewing Window:
Model types -05/06/09/10/13/14 professional
grade units include anti-glare anti-scratch front
viewing window as standard.
Model types -01/02/03/04/11 low-cost units do
not have this window fitted as standard but this
can be included as a cost option at time of
order.
Calibre UK Ltd
Cornwall House,
Cornwall Terrace,
Bradford, West Yorkshire
BD8 7JS, England
Tel
+44 (0)1274 394125
Fax
+44 (0)1274 730960
Web-site
www.calibreuk.com
Issue1.51 E&OE specifications subject to change without notice 10/12/07 All trademarks acknowledged.
