9
9G421-02/9G429-02 Module Specific Information
MULTICASTS
Displays the number of multicasts received.
LINK STATUS
Indicates whether there is a physical connection from this port to another device.
One of the following values appears:
• Link - There is a link signal present; there is a valid physical connection from
this port to another device.
• No Link - There is no link signal present; there is no valid physical connection
from this port to another device.
PORT TYPE
Displays the value GPIM-F01, which is an Ethernet Gigabit Fiber Channel 1 Gig,
MMF, SC.
PORT STATUS
Indicates the administrative status of the selected port. Possible values are:
• ENABLED - The port is turned on administratively.
• DISABLED - The port is turned off administratively.
APPLICATION
Displays BRIDGING , indicating that the port is operating as a bridge with a
high-speed backbone connection.
OPERATION MODE
Displays the value FULL DUPLEX . The port can transmit and receive data at the
same time, therefore, the port is running at 1000 Mbps.
PORT # (Modifiable)
Selects the port for which statistics are to be displayed.
Enable or disable ports from the Bridge Configuration Screen.
NOTE
