Adjustable fuel pump series, Installation – FASS FA C09 260G User Manual
Page 5
260 GPH
10 PSI (Approximately)
Adjustable Fuel Pump Series
A fuel pressure gauge is highly recommended to identify fuel filter life and to prevent engine damage!
“E”
To Engine
‘T’
Fuel Inlet Port
Boost
Compensation
Port
Adjustment Lock Nut
Set screw
Fuel Pressure Port
Installation
Step 1: Install Electrical Harness
Step 2: Prepare Suction & Return Lines
Step 3: Mount Fuel System
Step 4: Install Fuel Line
Step 5: Check/Set Pressure
Step 6: Review Installation
