FASS FA D08 260G - Manual (Page 15)

E. Disconnect factory fuel line bracket from inlet side of the factory fuel filter
and install the DIPF-1003 injection pump o-ring fuel fitting into this inlet
port.
F. Measure and cut fuel line. Insert PL-1003 90° Push-Lok fitting using oil. Install fitting to DIPF-1003.
Torque to 18 ft/lbs.
E. Disconnect inlet fuel line to the filter housing. Install DIPF-1003. Torque to
18 ft/lbs.
Note: Secure all fuel lines with cable ties. Cable ties are an economical way to prevent the
possibility of problems occurring!
These models can have the inlet fitting on top of the filter canister or on the side.
F. Measure and cut fuel line. Insert PL-1003 90° Push-Lok fitting using oil. Install fitting to DIPF-1003.
Torque to 18 ft/lbs.
Note: Secure all fuel lines with cable ties. Cable ties are an economical way to prevent the
possibility of problems occurring!
