A. Disconnect the fuel tank suction line from the steel fuel line in front
of the fuel tank.
B. Using oil, insert PLB-1212 into one end of the provided FL-1002
fuel line. Feed line over frame to the stock fuel connection.
C. Push the PLB-1212 into the stock suction line until you hear a click
and the tabs are locked in place.
D. Using an HC-1001 hose clamp, insert the QD-1002 into the other end of the provided FL-1002 fuel line
and secure. Loop this end over the frame to the factory steel fuel line disconnected in Step 2a. Oil the
rings inside the QD-1002 and slide over the line until you hear a click. Do not cut the line at this time.
NOTE: Hose clamps are not recommended for push lock fittings.
They will hold up to 300psi! Use oil on fittings and inside fuel
line when installing Push-Lok fittings
Some of the photo’s are of a different application, procedures are the same.
