AUTOMATIC WATER SOFTENER
DESIGN SPECIFICATIONS / DIMENSIONS
MODEL
MW-25
RATED CAPACITY
RATED EFFICIENCY
Â
See Rating Decal Located On The Softener
AMOUNT OF HIGH CAPACITY RESIN (lbs / cu ft) 36.4 / .70
RESIN TANK NOMINAL SIZE (in., dia x height) 8 x 40
SERVICE FLOW RATE (gpm)
PRESSURE DROP AT RATED SERVICE FLOW (psig)
See Rating Decal Located On The Softener
WATER SUPPLY MAXIMUM HARDNESS (gpg) 70
WATER SUPPLY MAX. CLEAR WATER IRON (ppm)

5
WATER PRESSURE LIMITS (min. / max. psi) z 20 – 125
WATER TEMPERATURE LIMITS (Min. / Max. o F) 40 – 120
WATER SUPPLY MINIMUM FLOW RATE (gpm) 3
REGENERATION CYCLE FLOW RATES (gpm)
FILL (flow to brine tank) .3
BRINING .15
BRINE RINSE (flow to drain) .10
MAX. BACKWASH 2.2
MAX. FAST RINSE 2.2
 Capacity to reduce clear water iron is substantiated by WQA test data.
These softeners conform to NSF/ANSI 44 for the specific capacity claims as verified and substantiated by test data.
 Efficiency rating is valid only at the minimum stated salt dose. These softeners were efficiency rated according to NSF/ANSI 44.
z Canada working pressure limits: 1.4 – 7.0 kg/cm
2
MW-25
