7
w w w . b i s s e l l . c o m
Item Part No. Part Name
1 203-7151 Tough Stain Brush Tool
2 203-7158 Solution/Clean Tank
(includes cap and insert assembly)
3 203-7144 Collection/Dirty Tank
(includes the airstack and float assembly)
4 203-7169 Quick Release Cord Wrap
5 203-7150 Vacuum Flex Hose Storage Bracket
(includes screw for assembly)
6 203-7159 Vacuum Flex Hose Clip
7 203-5014 Bottle Cap & Insert Assembly
CLEANING FORMULAS
8 79B9E 473 mL. 2X Concentrate Little Green ™
Advanced Formula
9 74R7E 473 mL. 2X Concentrate Pet Stain & Odor
Advanced Formula
T
roubleshooting
Reduced spray or no spray
Possible causes Remedies
1. Spray nozzle clogged 1. Clean spray nozzle
2. Solution/clean tank empty 2. Check/fill tank
3. Solution/clean tank insert clogged 3. Clean insert at bottom of clean/solution tank
4. Pump needs priming 4. Gently lift solution/clean tank while depressing
the spray trigger OR gently squeeze solution/
clean tank while depressing spray trigger
Deep cleaner won't pick up cleaning solution
Possible causes Remedies
1. Tank release latch is not closed properly 1. Lift up the tank release latch and press down
firmly to make sure it is in place
2. Poor tool position 2. Reposition tool on surface, follow
recommended cleaning procedures
3. Collection/dirty tank is full 3. Empty collection/dirty tank
4. Tool brush worn 4. Replace with new brush
5. Excess cleaning solution in vacuum flex hose 5. Lift hose and point upwards to allow water
in hose to flow into the collection/dirty tank
6. Incorrect cleaning formula 6. Use BISSELL Little Green formula only
Other maintenance or service not included in the manual should be performed by an
authorized service representative.
R
eplacement parts
1 2 3
4 5 6
7 8 9
