Humboldt HM-2415 Soil Volume Change Meter (PVC) User Manual
Page 8
Parts List
Item
Description
Requred
1
Frame Pot. Vol. Change Meter
1
2
1 000 lb. Single Proving Ring
1
3
Standard Compaction Hammer
(Not Shown)
1
4
Corundum Porous Stone
2
5
Proving Ring Adapter
1
6
~-20 x 1 3/4 Soc.Hd.Cap Screw
1
7
Cleaning Rod
1
10
Base
1
11
Crosshead
1
12
Supporting rod
2
13
Adjusting Screw
1
14
Lock Nut
1
15
Compaction Ring
1
16
Spacer Ring
1
17
Loading Disc
1
18
Lucite Container
1
19
Washer
2
21
Hex Nut 5/8-11 Th'd - St'l
2
22
"O"Ring 4~1.0 . X 4 3/4 0.0. X 1/8
1
23
5/16 -18 x 2 Hex Hd. Scr.
3
