INTRODUCTION
This manual is provided as an aid in setting up, operating and maintaining the
instrument. It does not supply the necessary information required to perform
the ASTM test. This information is copyrighted, and must be obtained from the
American Society for Testing and Material (ASTM).
http://www.astm.org
or by calling: 610-832-9585
K42000 & K42090 POWERTROL HEATER
INSTRUCTIONS, FOR USE
1. Plug heater into receptacle of the proper electrical characteristics
(K42000 - 115V) & (K42090 - 230V)
2. Turn unit on by turning knob (On/Off Switch) clockwise
3. Vary heat by turning knob clockwise from 0 to full.
4. To energize receptacle for stirrer or an accessory,
depress the front panel switch to ON.
STORAGE PROCEDURE
This laboratory test instrument consists of Electrical and Mechanical components.
Storage facilities should not be subject to extremes of high and low temperatures or
extremes of high and low moisture conditions. Storage facilities ·should be consistent
with an indoor laboratory environment.
NOTE: Unit is shipped in corrugated cartons and if long term storage is anticipated,
repacking with water resistant packing is recommended to insure a safe condition for the
equipment.
PARTS LIST
K42010 CLAMPS
K420-1-2A SHELL
K42001 HEATER 12S0W (llSV)- (H-2085.1)
K42091 HEATER 12S0W (220V)- (H-2085.1.4F)
O1O-115-005 WATTSTAT
010-230-004 WATTSTAT
060-002-005 RECEPTACLE (110V) NEMA #5-15
050-001-009 SWITCH
H-2060 FLASH CUP
H-2112 TEST FLAME BURNER
H-2600.11F THERMOMETER
