Humboldt H-1474 Centrifugal Extractor - Manual (Page 4)

www.humboldtmfg.com
HUMBOLDT
Testing Equipment for Construction Materials
Humboldt Mfg. Co.
875 Tollgate Road
Elgin, Illinois 60123 U.S.A.
U.S.A. Toll Free: 1.800.544.7220
Voice: 1.708.456.6300
Fax: 1.708.456.0137
Email: [email protected]
Warranty
Humboldt Mfg. Co. warrants its products to be free from defects in material or
workmanship. The exclusive remedy for this warranty is Humboldt Mfg. Co.,
factory replacement of any part or parts of such product, for the warranty of this
product please refer to Humboldt Mfg. Co. catalog on Terms and Conditions
of Sale. The purchaser is responsible for the transportation charges. Humboldt
Mfg. Co. shall not be responsible under this warranty if the goods have been
improperly maintained, installed, operated or the goods have been altered or
modified so as to adversely affect the operation, use performance or durability
or so as to change their intended use. The Humboldt Mfg. Co. liability under
the warranty contained in this clause is limited to the repair or replacement of
defective goods and making good, defective workmanship.
Specifications
Control
Variable speed, 0-3,600 rpm; brake for fast stopping
Motor 1/8 hp
Cover Precision-machined aluminum; removable, with integral
cup for adding solvent.
Housing Cast aluminum; sealed
Bowl Precision-machined aluminum; removable
Capacity H-1451, H-1452: 1,500 gram
H-1474: 3,000 gram
Filter Discs 25 included
Dimensions 12”w x 22”d x 20”h (305mm x 559mm x 508mm)
H-1452: 17”w x 22”d x 20”h (432 x 559 x 508 mm)
Weight H-1451, H-1452: Net 75 lbs. (34 kg.);
Shipping 85 lbs. (38 kg)
H-1474: Net 103 lbs. (47 kg.);
Shipping 140 lbs. (63 kg.)
