Humboldt H-4210A Portable, Static Cone Penetrometer - Manual (Page 6)

Item Description
1
Head Assembly
(includes items 2-7, 19 & 20)
2 Handle (2 required)
3 Body
4 Adjustment Screw
5 “O” ring (2 required)
6 Piston
7 Insert
8
2-ft Starter Rod Assembly
(includes items 9 & 10)
9 2-ft Starter Inner Rod
10 2-ft Outer Rod
11
2-ft Extension Rod Assembly
includes items 12 & 13)
12 2-ft Extension Inner Rod
13 2-ft Outer Rod
14 Cone Assembly
15 Gauge Guard (not shown)
16 Gauge Assembly (not shown)
17
“O” ring Packing Kit (not shown)
(includes 2 each of item 5)
Helpful Hint: Starter Inner Rods are 0.875" longer than
the similar-looking Extension Inner Rods (i.e. 2-ft Starter
Inner Rods are 24.875"OAL. The Extension Inner Rods
are 24" OAL).
