PARTS LIST / LISTA DE PARTES / LISTE DES PIÈCES DÈTACHÉES
DESCRIPTION / DESCRIPCIÓN / DESCRIPTION QUANTITY / CANTIDAD / QUANTITÉ PICTURE / ILLUSTRATION / DIBUJO
16.
2
Phillips Bolt
Perno Phillips
Boulon Phillips
14.
2
Allen Bolt – 1/4" x 1"
Perno Allen – 6 mm x 25 mm
Boulon Allen – 6 mm x 25 mm
13.
4
Allen Bolt – 1/4" x 1/2"
Perno Allen – 6 mm x 12 mm
Boulon Allen – 6 mm x 12 mm
Allen Bolt – 1/4" x 7/8"
Perno Allen – 6 mm x 22 mm
Boulon Allen – 6 mm x 22 mm
2
12.
11.
6
Allen Bolt – 1/4" x 3"
Perno Allen – 6 mm x 76 mm
Boulon Allen – 6 mm x 76 mm
10.
1
Bottom Shelf
Plataforma Inferior
Plateau Inférleure
Mid Shelf
Plataforma De Vidrio
Plateau En Verrre
1
9.
15.
2
Phillips Bolt
Perno Phillips
Boulon Phillips
