Cavity
Fuse
Circuits
8
15 Amp
Blue
Radio
9
10 Amp
Red
Roof Light, Horn, Anti-Theft
Alarm, Cargo Lamp and Tire
Pressure Control
10
5 Amp
Beige
Speed Control
11
15 Amp
Blue
Ignition Coil 6 Cyl.
12
10 Amp
Red
Heated Washer Nozzles
13
10 Amp
Red
Charge Air Cooler Circulation
Pump
14
10 Amp
Red
Diagnostic Socket
15
5 Amp
Beige
Residual Engine Heat Utilization
16
Spare
17
40 Amp
Orange
Electronic Stability Program
Cavity
Fuse
Circuits
18
40 Amp
Orange
Electronic Stability Program
19
40 Amp
Orange
Power Window
20
30 Amp
Green
Wiper Motor
21
30 Amp
Green
Seat Adjustment Right Side
22
30 Amp
Green
Seat Adjustment Left Side
23
15 Amp
Blue
Sound Booster (Amplifier)
24
30 Amp
Green
Seat Heater
25
20 Amp
Yellow
Pneumatic Control Unit, Rear
Window Defroster
26
20 Amp
Yellow
Central Locking
30
Spare (Coupe)
30
15 Amp
Blue
Radio (Roadster)
