MEX50 PNEUMATIC TIRE LIFT TRUCK SPECIFICATIONS

GENERAL

D150E-8

D160E-8

Power Type

Diesel

Operation Type

Sit-Down

Rated Capacity*

lbs. (kg)

33,000 (15000)

35,000 (16000)

Rated Load Center

in. (mm)

24 (600)

Load Distance (Front Axle Center to Fork Face) in. (mm)

29.5 (750)

Wheelbase

in. (mm)

122.0 (3100)

WEIGHT

Service Weight

lbs. (kg)

36,530 (16570)

37,920 (17200)

Axle Loading

Loaded

Front

lbs. (kg)

63,360 (28740)

66,450 (30140)

Rear

lbs. (kg)

6,240 (2830)

6,750 (3060)

Unloaded

Front

lbs. (kg)

15,900 (7210)

15,810 (7170)

Rear

lbs. (kg)

20,640 (9360)

22,110 (10030)

TIRES

Tire Type

Pneumatic

10 Tire Size

Front

11.00-20-16PR (I)

12.00-20-16PR (I)

Rear

11.00-20-16PR (I)

12.00-20-16PR (I)

11 Number of Wheel - Front/Rear (x=driven)

4x/2

12 Tread,

(center of tires)

Front

in. (mm)

69.7 (1770)

Rear

in. (mm)

74.4 (1890)

73.6 (1870)

DIMENSIONS

13 Tilting Angle (Forward/Backward)

degree

6/12

14 Mast Height, Lowered with Std. Mast

in. (mm)

128.7 (3270)

129.5 (3290)

15 Std. Free Lift with Std. Mast from Ground

in. (mm)

0.0 (0)

16 Maximum Fork Height**

in. (mm)

118 (3000)

17 Mast Height, Extended with Std. Mast

in. (mm)

188.2 (4780)

189.0 (4800)

18 Height, Overhead Guard

in. (mm)

110.6 (2810)

111.4 (2830)

19 Length, with Std. Forks

in. (mm)

233 (5920)

237 (6020)

20 Length, to fork face

in. (mm)

185 (4700)

189 (4800)

21 Width, at tire

in. (mm)

94.9 (2410)

97.6 (2480)

22 Forks (Thickness x Width x Length)

in. (mm)

3.3x7.5x48.0 (85x190x1220)

3.3x8.3x48.0 (85x210x1220)

23 Fork Carriage Class

Pin Mount

24 Width, Fork Carriage

in. (mm)

86.6 (2200)

25 Ground Clearance Under the Mast

in. (mm)

9.8 (250)

10.6 (270)

at the center of wheelbase in. (mm)

13.8 (350)

14.6 (370)

26 Right Angle Stacking Aisle plus load length † in. (mm)

256.7 (6520)

262.6 (6670)

27 Turning Radius

in. (mm)

171.3 (4350)

177.2 (4500)

PERFORMANCE

28 Travel Speed

(FWD)

Loaded, 1st/2nd/3rd mph (km/h)

5.6/12.1/17.1 (9/19.5/27.5)

5.9/12.4/17.4 (9.5/20/28)

Unloaded, 1st/2nd/3rd mph (km/h)

5.9/13.0/20.2 (9.5/21/32)

6.2/13.4/20.5 (10/21.5/32)

29 Lifting Speed (Loaded/Unloaded) fpm (mm/s)

64/69 (325/350)

63/68 (320/345)

30 Lowering Speed (Loaded/Unloaded) fpm (mm/s)

79/79 (400/400)

31 Max. Drawbar Pull (Loaded)

lbs. (kN)

21,350 (94)

21,170 (94)

32 Max. Gradeability (Loaded 1.5km/h, 3min rating) %

33 Service Brake (Operation/Control)

Foot/Hydraulic, Powered

34 Parking Brake (Operation/Control)

Hand/Mechanical

35 Steering (Type)

Hydraulic Power Steering

DRIVE

36 Maker/Model

Komatsu SAA6D107E-1

37 Rated Output, SAE net

HP (kW)

164 (122)

38 Rated Speed

min-1

2200

39 Max Torque, SAE net lb.- ft. (N-m) @ min-1

424 (575)@1600

40 No. of Cylinder/Displacement

cu.in (cm

)

6/408 (6690)

OTHER

41 Fuel Tank Capacity

US gal (Ltr)

74.0 (280)

42 Relief Pressure for Attachment

psi (bar)

3,118 (215)

43 Hydraulic Tank Capacity

US gal (Ltr)

55 (210)

44 Clutch

Torque Converter

45 Battery (Voltage/Capacity at 5-hour rating)

V/Ah

24/80

NOTE: Most values shown in this publication are rounded. Therefore, direct conversion between metric and English or Imperial may be slightly different from those
shown. The performance of machines is affected by the condition of the truck and how it is equipped, as well as the nature and condition of the operating area.
If these specifi cations are critical or if your needs exceed the specifi cations shown here, discuss the proposed application with your authorized dealer.

*Optional masts, attachments, longer load dimensions, and higher lifting heights may result in downrating of the capacity. Contact your authorized dealer.
**Other mast heights available. See MAST DATA chart for other standard mast heights. Contact your authorized dealer.

†Add load distance and clearance. Contact your authorized dealer.
