Amico Surface Mount Emergency Oxygen Inlet Station (Low Pressure) - Manual (Page 5)

www.amico.com 5
Repair and Replacement Parts List:
1. V-X-RK-NIB-10 Repair kit for 1” ball valve - seats and O-rings
2. V-X-VLV-HAND-M Valve handle sleeve for 1”
3. V-X-GAUGE-100 Gauge 100 psi/690 kPa – 1/8” NPT
4. M-X-OXF-PLUG-LP 1” NPT hex-head plug
5. V-X-BOX-PLUG Box plug for oxygen inlet station
Bottom view
Front view
1
3
2 4
5
Back view
Front view
5
2 4
3
1
Recessed Mount Surface Mount
