43 X-Press
Operating Instructions
7. Parts & Assembly
AS3243
IT EM PAR T NO DESCRIPT ION QT Y COMMENT S
1 AS2157 DISC FRAME ADJUSTER ASSEMBLY 2
2 AS2158 LIFT CIRCUIT - HYD. COMPONENT LAYO 1
3 AS2748 WING CIRCUIT - HYD. COMPONENTS 1
4 AS2794 X-PRESS DRAWBAR ASSEMBLY 1
5 AS2849 LOADBINDER ASSEMBLY 530mm 1
6 AS3246 DISC FRAME RH 4.6m 1
7 AS3247 DISC FRAME ASSEMBLY LH 1
8 AS3252 ROLL FRAME ASSEMBLY - RH 4.6m 1
9 AS3253 ROLL FRAME ASSEMBLY - LH 4.6m 1
10 AS3258 DD700 ROLL ASSEMBLY RH 1
11 AS3259 DD700 ROLL ASSEMBLY LH 1
12 AS3265 LIFT AXLE ASSEMBLY 1
13 AS3266 CHASSIS ASSEMBLY 1
14 P13013 MANUAL CASE Ø100 1
15 P14201 HYDRAULIC KIT - X-PRESS 4.2m 1
16 P15845 MANUAL - X-PRESS 1
17 P15895 WIRING LOOM - TRAILED X-PRESS 1
18 P15952 STICKER KIT X-PRESS 4.6m 1
19
20
AS2818 27./10-12 RUBBER ROLL ASSEMBLY 2 (NOT SHOWN)
21 AS3452 DDL600 - X-PRESS 4.6M - BOLT ON KIT 1 (NOT SHOWN)
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
GEN E R AL AS SE MBLY - 4.6m
