25 ST-Bar
Operating Instructions
Parts & Assembly
AS3234
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 H00230085 BUSH Ø38xØ30x35 2
2 H00230086 BUSH Ø34xØ30x40 2
3 H00230087 BUSH Ø34xØ30x25 1
4 H00230098 BUSH Ø44xØ36x30 1
5 H00370060 ROLL PIN Ø10x50 2
6 H00370074 ROLL PIN Ø6x50 2
7 H34060801 TINE ARM LH 1
8 H34060803 TINE ARM RH 1
9 H34060806 CLAMP BASE 1
10 H34060807 PIN Ø30x178 1
11 H34060809 SPRING Ø84xØ19x372 1
12 H34060816 SPRING Ø50xØ10x273 1
13 H34060822 BUSH Ø40xØ34x105 1
14 H34060842 SPRING PIVOT 1
15 H34060844 SPRING TOP PLATE 1
16 H34060845 SPRING TUBE 1
17 H34060846 BOLT M24x360 GR8.8 1
18 H34080847 WASHER Ø57xØ26x8 1
19 P00742 BOLT M20x120 GR. 8.8 2
20 P02008 NUT LOCK M16 3
21 P02485 R CLIP Ø6x120 1
22 P02602 WASHER FLAT M16 6
23 P02603 WASHER FLAT M20 4
24 P02649 BOLT M16x90 GR. 8.8 1
25 P03116 BOLT M20x90 GR. 8.8 2
26 P05207 PIN Ø16x73 1
27 P12911 TERRAGRIP CONVERTER 1
28 P14517 CLAMP PLATE 132x92/82 1
29 P14588 BOLT M16x75 GR10.9 2
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
ST U N IT & T ER R AGR IP CON VER T ER
