Great Plains 3PYPA-1238 12 Row 38-Inch Quick Start - Manual (Page 4)

Quick Setup Guide for IntelliAg Model 3PYP 12 Row Single Row Air Pro
11001-1531A-201209
©2012 DICKEY-john Corporation
Specifi cations subject to change without notice.
4
STEP 11: Clutch Folding Module (CFM) Setup
The CFM is installed in the cab to control row clutches, wing fold, marker tilt, and marker
fold.
At the Main Work screen, press the Clutch CFG button to access the Clutch Confi gu-
ration screen and verify that the correct # of clutches are confi gured for the system.
The Clutch CFG button
only appears as a top level button when a planter
output module and clutch folding module are installed.
1.
2.
O U T P U T
1 - 3
# O F
R O W S R O W
# ’ s
4 - 9
1 0 - 1 2
LEFT
CENTER
RIGHT
3
6
3
# of Clutches 3
TABLE H:
Accessory
Setup
Default Value
or Value to
Enter Instructions/Defi nitions
Hopper Setup
# of Hoppers 1 # of hopper sensors connected to each module (4 sensors
maximum). # of hopper data items for each listed module and
the Hopp #’s value will automatically populate if Auto Confi g is
used to confi gure installed sensors.
Logic Level Active Lo Sets the active state to low signifying that an alarm is gener-
ated if the sensor’s output is in a low state. Use this setting
if the connected sensor outputs a low condition when empty
similar to the DICKEY-john hopper sensor.
Alarm Delay 5 sec Controls the delay time between the detection of a high/low
hopper alarm condition and the generation of the resulting
alarm. The value is entered in seconds.
Channel Assigns hopper sensor to channel.
RPM Setup
High Alarm
(fan speed)
3000 rpm Sets the RPM value at which a high RPM warning error is
generated.
Low Alarm
(fan speed)
1800 rpm Sets the RPM value at which a low RPM warning error is
generated.
High Alarm Delay 10 sec Establishes the delay between the detection of a high RPM
alarm condition and the resulting alarm display. The value is
entered in seconds.
Low Alarm Delay 10 sec Establishes the delay between the detection of a low RPM
alarm condition and the resulting alarm display. The value is
entered in seconds.
RPM Constant 3 pulses/rev Number of pulses per sensor revolution.
RPM Filter 0 Filters the signal out of the RPM sensor.
Disable Control
on Low Alarm
Disabled Allows for disabling of all control channels if the RPM value of
the selected sensor falls below the low alarm level setting.
STEP 10: Accessory Sensor Setup
Hopper Assignment
At the Main Work screen, press the Next Page button .
Press the Module Confi guration button to display the Module Confi guration
screen.
At the Module Confi guration screen, press the Hopper Assign button
.
Press Hopper Set button .
Enter desired values using Table H as reference.
RPM Assignment
At the Module Confi guration screen, press the Accessory Assignment button .
Press the RPM Setup button . NOTE: There must be at least 1 RPM sensor
confi gured before the RPM Setup button appears on the screen.
Enter desired values using Table H as reference.
1.
2.
3.
4.
5.
6.
7.
8.
TABLE G:
Speed Set
Default Value
or Value to
Enter Instructions/Defi nitions
Source Digital Frequency Select CAN Ground if radar is connected to ISO tractor cab
harness. Select Digital Frequency if radar or hall-effect is
connected to WSMT actuator harness.
Gspd Constant 12192 Input based on pulse count produced by the ground speed
sensor over 400’ distance. See Operator’s manual for
calibration instructions.
Shutoff Speed 0.5 mph Set desired minimum ground speed allowed before the
system shuts off.
Minimum
Override
2.0 mph Set to operate when actual ground speed falls below the des-
ignated value. Control will operate at this speed until actual
ground speed rises above minimum override speed or actual
speed drops below shutoff.
Master Sw
Timeout
10 Set to desired number of seconds system shuts off if the
master switch is turned on and there is no ground speed.
Toggle master switch to restart the system and turn off alarm.
Gspd Fail Alarm
Delay
5 Set to desired number of seconds alarm sounds after the
ground speed is zero and seed fl ow continues. (Monitor only)
Precharge
Ground Speed
0 Set to the desired speed the system will use when a pre-
charge time has been enabled for a control channel. Refer
to Table C1: Planter Control Setup for Precharge Time. This
setting will only display when a Precharge Time has been
entered.
Implement Lift Enabled Implement lift switch, when enabled, displays an implement
lift indicator on the Main Work screen indicating implement lift
position as up or down. Control channels can be turned on
and off without using the master switch.
STEP 9: Speed Set Calibration Setup
At the Main Work screen, press the Speed Set button .
Enter desired values using Table G as reference.
Press the Work Screen button
when ground speed calibration confi gurations
are complete to return to the Main Work screen.
1.
2.
3.
