47 X-Press
Operating Instructions
7. Parts & Assembly
AS2067
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 J220571010 DD LIGHT ROLL FRAME 4.0m 1
2 P01834 BEARING SCJ 50 2
3 AS2069 DDLIGHT ROLLER 4m C/W SIMBA DD RINGS 1
4 P12758 STUB AXLE END WASHER Ø50 2
5 J910141650 C/S BOLT M16 8
6 P00874 BOLT M20x70 GR. 8.8 4
7 P02009 NUT LOCK M20 4
8 J220561120 SCRAPER XPRESS 3PL STD 28
9 P02284 BOLT U M16 GR8.8 115x88 28
10 P02008 NUT LOCK M16 56
11 P02602 WASHER FLAT M16 56
12 P02038 WASHER SPRING M16 8
13 P01358 NUT PLAIN M16 8
14 P10367 CAPSCREW M12x40 GR10.9 4
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
X-PRESS 4.0m PROACT IVE - DDLIGHT ROLL UNIT
