AS3654 ST TOOL BAR 4.0M
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS2962 ST TINE ASSEMBLY 7
2 AS3657 ST UNIT & CONVERTER 7
3 P00012 BOLT M20x100 GR. 8.8 4
4 P01054 PIN Ø25x140 1
5 P01224 BOLT M20x180 GR. 8.8 4
6 P01352 BOLT M16x150 GR. 8.8 4
7 P02008 NUT LOCK M16 'TYPE T' 4
8 P02484 LYNCH PIN CAT 2 6
9 P02485 R CLIP Ø6x120 7
10 P02602 WASHER FLAT M16 7
11 P04959 TOPLINK CAT 2 9" 1
12 P05122 SERIAL PLATE 1
13 P05207 PIN Ø16x73 6
14 P06857 BOLT M6x12 GR. 8.8 4
15 P07543 PLASTIC END CAP 40x40 6
16 P12725 POINT REMOVAL TOOL 1
17 P13092 RIVET Ø3x10x Ø6 HEAD 4
18 P13775 PARKING STAND LEG 2
19 P14517 CLAMP PLATE 132x92/82 2
20 P14754 BALL CAT 3 LOWER Ø37 2
21 P14977 ST BAR 4.0M 1
22 P14996 CAT 3 LOWER LINK PIN TO SUIT ST BAR 2
23 P14997 PARKING STAND LEG 2
24 P14998 PARKING STAND LEG 2
25 P14999 LOWER BALL SPACER CAT 3 2
26 P15003 PARKING STAND BASE 2
27 P15004 RETAINING PLATE 2
28 P17815 MANUAL HOLDER - COMPLETE 1
29 P17906 UPPER LINK PIN - CAT 3 1
30 P17918 PIN - Ø36x182 2
31 P17920 MANUAL - ST-TOOLBAR 2011 1
