Great Plains P12720 - Manual (Page 21)

21 X-Press
Operating Instructions
3. Technical Data X-Press
* It is important to correctly match your implement to your tractor for optimum performance.
Two power ratings are listed above. The lower HP figure relates to tracked tractors, the
higher HP figure relates to wheeled tractors.
3. Technical Data
4.6m 5.5m 6.6m
Working Width 4600mm 5500mm 6600mm
Transport Width 2980mm 2980mm 2980mm
Transport Height 2975mm 3450mm 3950mm
Length 7000mm 7000mm 7000mm
Weight 4700kg 6230kg 7170kg
No. of Discs 36 44 52
Tractor Power Required (H.P.)* 140/150 160/180 200/220
