Page 48
Revision
Comments
Part Description
Part No.
Ref.
BRG BALL 1.18ODX2.44OD
822-216C
58.
WASHER FLAT 3/4 HARD ASTMF436
804-093C
59.
FERT DRIVE WHL BEARING SPACER
407-600D
60.
SNAP RING INT 2.44 OD
800-382C
61.
FERT DRIVE SHAFT WELDMENT
407-463H
62.
HHCS 1/2-13X3 1/4 GR5
802-099C
63.
RH GND DRIVE WL CHAIN GRD WLMT
402-427H
64.
IDLER PIVOT TB 1ODX.56IDX1.84L
407-598D
65.
TUBE RND 1 OD X 7/32W X 3.31
120-313D
66.
HHCS 1/2-13X4 1/2 GR5
802-413C
67.
LOCK COLLAR, 7/8 HEX W/ SET SC
402-025S
68.
CHAIN RL #40 52 PITCHES
136-078D
69.
GND DRIVE WHL JACKSHAFT 11.063
402-677D
70.
NUT HEX 5/8-11 PLT
803-021C
71.
CHAIN RL #40 76 PITCHES
136-096D
72.
FERT DRIVE SHAFT HEAD BUSHING
407-584D
73.
U-BOLT 5/8-11 X 4 1/32 X 5 1/2
806-184C
74.
U-BOLT 5/8-11 X 7 1/32 X 8 1/2
806-052C
75.
WASHER LOCK SPRING 5/8 PLT
804-022C
76.
GROUND DRIVE WHEEL MOUNT
402-424H
77.
PIN COTTER 1/8 X 1 1/2
805-225C
78.
YP1630 GND DR RH CHAIN ROUTING
848-974C
79.
YP1630 GND DR LH CHAIN ROUTING
848-973C
80.
CHAIN RL #40 X 104 PITCHES
136-139D
81.
SPKT 40C19 X 7/8 HEX BORE
808-149C
82.
SPKT 40C28 X 7/8 HEX BORE
808-155C
83.
GROUND DRIVE WHEEL LOCKUP ARM
417-044D
84.
PIN WIRE RETAINING 1/4 X 1 3/4
805-065C
85.
CHAIN RL #40 122 PITCHES
136-016D
86.
YP1630 GND DR RH CHAIN ROUTING
848-974C
87.
YP1630 GND DR LH CHAIN ROUTING
848-973C
88.
SPKT 40C20 X 7/8 HEX BORE
808-276C
89.
401-832P
- 48 -
07/22/14
Wing Ground Drive (402-420K) (continued)
(Applies to YP1630F only)
