Quick Setup Guide for IntelliAg Model YP24 15”

11001-1430C-200907

STEP 8: Speed Set Calibration Setup

At the Main Work screen, press the Speed Set button

Enter desired values using Table E as reference.
Press the Work Screen button

when ground speed calibration confi gura-

tions are complete to return to the Main Work screen.

1.
2.
3.

TABLE E:

Speed Set

Default Value

or Value to

Enter

Instructions/Defi nitions

Source

Digital Frequency

Select CAN Ground if radar is connected to ISO tractor cab harness.

Select Digital Frequency if radar or hall-effect is connected to WSMT

actuator harness.

Gspd Constant

12192

Input based on pulse count produced by the ground speed sensor

over 400’ distance. See Operator’s manual for calibration instruc-

tions.

Shutoff Speed

0.5 mph

Set desired minimum ground speed allowed before the system

shuts off.

Minimum Over-

ride

2.0 mph

Set to operate when actual ground speed falls below the designated

value. Control will operate at this speed until actual ground speed

rises above minimum override speed or actual speed drops below

shutoff.

Master Sw

Timeout

Set to desired number of seconds system shuts off if the master

switch is turned on and there is no ground speed. Toggle master

switch to restart the system and turn off alarm.

Gspd Fail Alarm

Delay

Set to desired number of seconds alarm sounds after the ground

speed is zero and seed fl ow continues. (Monitor only)

Precharge

Ground Speed

Set to the desired speed the system will use when a precharge time

has been enabled for a control channel. Refer to Table C1: Planter

Control Setup for Precharge Time. This setting will only display when

a Precharge Time has been entered.

Implement Lift

Enabled

Implement lift switch, when enabled, displays an implement lift indi-

cator on the Main Operate screen indicating implement lift position

as up or down. Control channels can be turned on and off without

using the master switch.

STEP 10: Clutch Folding Module (CFM) Setup

The CFM is installed in the cab to control row clutches, marker, fold, fertilizer on/off,
lift and hitch.

At the Main Work screen, press the Clutch CFG button to access the Clutch
Confi guration screen and verify that the correct # of clutches are confi gured for the
system.
The Clutch CFG button

only appears as a top level button when a planter

output module and clutch folding module are installed.

STEP 9: Accessory Sensor Setup

Hopper Assignment

At the Main Work screen, press the Next Page button

Press the Module Confi guration button

to display the Module Confi guration

screen.
At the Module Confi guration screen, press the Hopper Assign button

Press Hopper Set button

Enter desired values using Table F as reference.

RPM Assignment

At the Module Confi guration screen, press the Accessory Assignment button

Press the RPM Setup button

or NOTE: There must be at least 1 RPM sen-

sor confi gured before the RPM Setup button appears on the screen.
Enter desired values using Table F as reference.

1.
2.

3.
4.
5.

TABLE F:

Accessory

Setup

Default Value

or Value to

Enter

Instructions/Defi nitions

Hopper Setup

# of Hoppers

2 (base unit)

2 more (optional)

# of hopper sensors connected to each module (4 sensors

maximum). # of hopper data items for each listed module and the

Hopp #’s value will automatically populate if Auto Confi g is used to

confi gure installed sensors.

Logic Level

Active Lo

Sets the active state to low signifying that an alarm is generated

if the sensor’s output is in a low state. Use this setting if the con-

nected sensor outputs a low condition when empty similar to the

DICKEY-john hopper sensor.

Alarm Delay

5 sec

Controls the delay time between the detection of a high/low hopper

alarm condition and the generation of the resulting alarm. The value

is entered in seconds.

Channel

Assigns hopper sensor to channel.

RPM Setup

High Alarm (fan

speed)

4200 rpm

Sets the RPM value at which a high RPM warning error is gener-

ated.

Low Alarm (fan

speed)

2900 rpm

Sets the RPM value at which a low RPM warning error is generated.

High Alarm Delay

10 sec

Establishes the delay between the detection of a high RPM alarm

condition and the resulting alarm display. The value is entered in

seconds.

Low Alarm Delay

10 sec

Establishes the delay between the detection of a low RPM alarm

condition and the resulting alarm display. The value is entered in

seconds.

RPM Constant

3 pulses/rev

Number of pulses per sensor revolution.

RPM Filter

Filters the signal out of the RPM sensor.

Disable Control

on Low Alarm

Disabled

Allows for disabling of all Control Channels if the RPM value of the

selected sensor falls below the low alarm level setting.

O U T P U T

1 - 1 8

# O F
R O W S

R O W
# ’ s

1 9 - 2 9
3 0 - 4 7

LEFT

CENTER
RIGHT

# of Clutches
