9 Simba DTX AR
604-108P
2013-02-08
Parts
44006 DISC UNIT LH
ITEM PART NO DESCRIPTION QTY COMMENTS
1 601-024D PLATE 12MM 1
2 601-034K DISC UNIT RH 1
3 601-440D HHCS M24X3X185 GR8.8 SPTHD 1
4 604-062D TRACK ARM 1
5 604-063D BUSH Ø36XØ16.5X31MM 2
6 604-064D BUSH Ø24XØ16X13MM 1
7 802-976C HHCS M12X1.25X20 GR8.8 5
8 803-282C NUT HEX NYLOCK M16X2.00 GRB PT 4
9 803-413C NUT CASTLE M24X3 1
10 803-415C NUT HEX M12X1.5 NYLON INSERT 3
11 804-159C WASHER SPRING LOCK M12 PLT 5
12 804-247C WASHER FLAT M16 PLT 7
13 805-465C LYNCH PIN CAT 0 1
14 807-313C SPRING COMP 80 X 20MM 1
15 820-460C DISC BLADE Ø515X6 1
16 842-034C HHCS M16X2X80 GR8.8 2
17 842-038C HHCS M12X1.75X50 GR10.9 SPTHD 3
18 842-066C HHCS M16X2X55 GR8.8 2
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
