Parts & Assembly
Table of contents
DTX 300 Complete Machine Assembly ..... 4
DTX 350 Complete Machine Assembly ..... 6
DTX 300 Mainframe Assembly .................. 8
DTX 350 Mainframe Assembly ................ 10
Toolbox Assembly .................................... 12
Pro-Lift Tine Assembly
(Retrofit to 2009 Model)
... 14
Pro-Lift Tine Assembly
(2010 Model)
.............. 16
LD Tine Assembly
(2010 Model)
..................... 18
DTX 300 DD Lite Roll Assembly .............. 20
DTX 350 DD Lite Roll Assembly .............. 22
DD Lite Scraper Assembly....................... 24
DTX 300 Aqueel 2 Assembly ................... 26
DTX 300 DD600 Roll Assembly............... 28
DTX 350 DD600 Roll Assembly............... 30
DD600 Axle Assembly - 6 Rings .............. 32
DD600 Axle Assembly - 7 Rings .............. 34
DD600 Axle Assembly - 8 Rings .............. 36
DD600 Pillar Assembly ............................ 38
DTX 350 Front Light Assembly ................ 40
DTX 350 Rear Light Assembly ................ 42
TurboJet Mounting Assembly .................. 44
Distributor Head Assembly ...................... 46
Radar Mounting (Aqueel 2) ..................... 48
Parts
3 Simba DTX
604-107P
2013-06-03
