Ng-12 drop seeder components cont – Great Plains NG12 Operator Manual User Manual
Page 27
8/5/2004
202-457M
25
Parts
1.
110-015D
LID LATCH STRAP
2.
110-016D
LID HINGE STRAP SPACER
3.
119-224D
LID LATCH
4.
807-001C
SPRING EXT LID HING
5.
802-007C
HHCS 5/16-18X3/4 GR5
6.
803-001C
NUT HEX 10-24 PLT
7.
805-014C
PIN CLEVIS.491 X 2 49/64 USEL
8.
805-019C
PIN COTTER 5/32 X 1 PLT
9.
802-167C
HHCS 1/4-20X1 1/2 GR5
10.
803-007C
NUT LOCK 1/4-20 PLT
11.
801-028C
SCREW RD HD 5/16-18 X 1/2 PLT
12.
890-015C
ANCHOR BRACKET
13.
800-107C
SNAP RING INT 2.165
14.
802-196C
HFSS 1/4-20X5/8 GR5
15.
816-004C
VINYL SEAL 3/8 X 1/2 (PER FT)
16.
816-001C
VINYL SEAL 3/8 X 5/8/FT
17.
119-146H
12’ BOX LID WELDMENT
18.
838-442C
DECAL NATIVE GRASS SEED RATE
19.
838-428C
DECAL NATIVE GRASS IMPORTANT
20.
838-265C
DECAL REFLECTOR AMBER 1 1/2X9
21.
838-266C
DECAL REFLECTOR RED 1 1/2X9
22.
838-267C
DECAL REFLECTR DAYTIME 1 1/2X9
23.
822-071C
BEARING CAST 3/4 - 2 BOLT
24.
802-010C
HHCS 5/16-18X1 1/4 GR5
25.
804-009C
WASHER LOCK SPRING 5/16 PLT
26.
803-008C
NUT HEX 5/16-18 PLT
27.
803-088C
NUT HEX LOCK 1/4-20 FLG
28.
803-001C
NUT HEX 10-24 PLT
29.
804-004C
WASHER INTERNAL STAR #10 PLT
30.
816-051C
GASKET GRASS SEED METER WHEEL
31.
801-003C
SCREW RD HD SLT 10-24X1/2 PLT
32.
202-055D
GRASS SEED METER WHEEL COVER
33.
806-132C
U-BOLT 3/8-16 X 3 1/32 X 2 3/4
34.
123-563D
SMV MOUNT BRACKET
35.
818-055C
DECAL SLOW MOVING-GALV. BACKED
36.
802-159C
HHCS 5/16-18X1 GR5
37.
804-010C
WASHER FLAT 5/16 USS PLT
38.
802-005C
HHCS 1/4-20X1 GR5
39.
838-441C
DECAL NG-12
40.
801-018C
SCREW RD HD 1/4-20 X 5/8
41.
822-057C
BEARING PILLOW BLK PB 3/4W/HSG
42.
804-006C
WASHER LOCK SPRING 1/4 PLT
43.
803-006C
NUT HEX 1/4-20 PLT
44.
202-453K
12’ NG TRAY ASSEMBLY
45.
804-007C
WASHER FLAT 1/4 SAE PLT
46.
202-007D
GRASS METER SPROCKET
47.
801-023C
SCREW SET SH 3/8-16X3/8 TYPE C
48.
812-054C
CASTING GRASS SEED FEEDER CUP
49.
800-004C
SNAP RING EXT BASIC 1.880
50.
202-183D
NG BOX SHAFT
51.
816-008C
RUBBER LID LATCH
52.
804-013C
WASHER LOCK SPRING 3/8 PLT
53.
803-014C
NUT HEX 3/8-16 PLT
54.
838-160C
DECAL 3 COLOR STRIPE 2.50 WIDE
55.
838-161C
DECAL LOGO&GP F/STRIPE 4 X 24
56.
800-144C
CLAMP WRM DRV #40 SS (2.06-3)
57.
202-206D
NG SEEDER HOSE
58.
202-207D
NG BEARING HOUSING
59.
802-014C
HHCS 3/8-16X3/4 GR5
60.
804-012C
WASHER FLAT 3/8 SAE PLT
61.
822-103C
BRG 30MM B X 55MM OD
62.
838-634C
DECAL GRAPHITE W/NATIVE GRASS
NG-12 Drop Seeder Components Cont.
