INSTALLATION
REAR AV Connection
SOURCE
MENU
CH+
CH-
VOL+
VOL-
1
SOURCE
Display the input source menu.
CH+
or
CH-
to select items in MENU.
when TV is in standby mode, press
CH+
or
CH-
button in TV control panel will power
on the TV.
2
MENU
3
CH+/CH-
4
VOL+/VOL-
To display main MENU.
In TV mode
press
CH+
or
CH-
to change the channel up and down.
In MENU,press
Adjust sound level.
In MENU,adjust the item that you selected.
CONTROL PANEL
All the terminals are(from left to right):
AC POWER SOCKET,HDMI,VGA ,PC AUDIO(HDMI in DVI mode share this audio channel),
CVBS,S-VIDEO,YPbPr,ANTENNA.
Note: CVBS,S-VIDEO and YPbPr share one audio channel.
ANT
AV
S-VIDEO
L
R
AUDIO
INPUT
YPbPr
INPUT
Y
Pb
Pr
AUDIO
VGA INPUT
VGA INPUT
100-240V~ 50/60Hz
AC-INPUT
HDMI
ANT
AV
S-VIDEO
L
R
AUDIO
INPUT
YPbPr
INPUT
Y
Pb
Pr
AUDIO
VGA INPUT
VGA INPUT
100-240V~ 50/60Hz
AC-INPUT
HDMI
