Revision Comments Part Description Part No. Ref.
DRV WHL SPRING TRUNION CASTING 812-442C 58.
SPRING COMP 2 1/2ODX3/8X12 7/8 807-159C 59.
SPRING STOP STAMPING SMALL 153-053D 60.
NUT HEX FLANGE 1/2-13 GR G PLT 803-193C 61.
NUT HEX JAM 1/2-13 PLT 803-036C 62.
ADJ. YOKE END 121-166D 63.
PIN ROLL 1/4 X 1 1/2 LG PLT 805-180C 64.
7/8 HEX SHAFT SPACER TB X 9/32 402-266D 65.
GRND DRIVE FERT PUMP MNT 407-526H 66.
RHSNB 1/2-13X1 1/2 GR5 802-106C 67.
DRIVE ARM OUTER BRG PLT BOLTED 407-745D 68.
(YP425A S/N B1015N+) (YP625A S/N
B1062Q+) (YP825A S/N B1033S+)
PIN HITCH 3/4 X 5 1/4 USEABLE 805-195C 69.
DECAL CAUTION TIRE 36 PSI 818-855C 70.
401-651P - 184 - 07/22/14
Table of Contents Part Number Index
Liquid Fertilizer Drive (YP425A S/N B1009N+) (YP625A S/N B1044Q+) (YP825A
S/N B1015S+) (continued)
(Applies to YP425A, YP625A, YP825A only)
