Great Plains SL600 Parts Manual - Manual (Page 5)

39 Simba SL
Operating Instructions
7. Parts and Assembly
AS4259 SL 400 TOP LEVEL ASSEMBLY 2011
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS2790 LINKAGE PULL POINT ASSEMBLY 1
2 AS2824 REAR LIGHT BRACKETS 1
3 AS2929 STICKER KIT LAYOUT SIMBA SL 4m DTD 1
4 AS2955 DISC GANG ASSEMBLY REAR RH 1
5 AS2956 GANG ASSEMBLY REAR LH 1
6 AS2958 DISC GANG ASSEMBLY FRONT RH 1
7 AS2960 GANG ASSEMBLY FRONT LH 1
8 AS2964 WING FRAME ASSEMBLY RH 4M - DTD 1
9 AS2965 WING FRAME ASSEMBLY LH 4M - DTD 1
10 AS3133 FRONT LIGHT ASSEMBLY 1
11 AS3134 SIMBA SL HIGH LATCH WING LOCK 1
12 AS3135 ROLL FRAME ASSEMBLY RH - 4m 1
13 AS3136 ROLL FRAME ASSEMBLY LH - 4m 1
14 AS3147 DEPTH CONTROL ROD ASSEMBLY 2
15 AS3277 WIRING LOOM LAYOUT SL 400/500/600 RANGE 1
16 AS4283 CHASSIS ASSEMBLY 1
17 AS4284 LIFT AXLE ASSEMBLY 1
18 AS4289 LINKAGE DRAWBAR 1
19 AS4307 HK - SIMBA SL DTD 4 & 5 QUICK LOCK 1
20 AS4327 TINE FRAME ASSEMBLY RH 4M 1
21 AS4328 TINE FRAME ASSEMBLY LH 4M 1
22 AS4370 ROLL DDL600 RH-4m HIGH LEVEL SCRAPER RAILS 1
23 AS4371 ROLL DDL600 LH-4m HIGH LEVEL SCRAPER RAILS 1
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
