53 SL700
Operating Instructions
7. Parts & Assembly
AS2470 WING RH C/W TINE FRAME
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS2457 TINE FRAME LINK 5
2 AS2458 TINE FRAME RH ASSEMBLY 1
3 AS2518 DISC UNIT RH 13
4 AS2519 DISC UNIT LH 13
5 AS2553 TINE FRAME LINK WITH TRIGER 1
6 AS2923 FRONT WHEEL RIGHT HAND 1
7 H00170108 SPRING Ø4 L 149 2
8 P00015 BOLT M24x75 GR. 8.8 1
9 P00071 NIPPLE - GREASE 7
10 P00407 BOLT M20x80 GR. 8.8 4
11 P01901 BOLT M16x80 GR. 8.8 82
12 P02007 NUT LOCK M12 6
13 P02008 NUT LOCK M16 'TYPE T' 86
14 P02009 NUT LOCK M20 4
15 P02010 NUT LOCK M24 6
16 P02483 LYNCH PIN CAT 1 1
17 P02601 WASHER FLAT M12 12
18 P02602 WASHER FLAT M16 168
19 P02603 WASHER FLAT M20 8
20 P02604 WASHER FLAT M24 Ø50 13
21 P02649 BOLT M16x90 GR. 8.8 4
22 P03087 BOLT M12x50 GR. 8.8 4
23 P03117 BOLT M24x120 GR. 8.8 1
24 P04754 NUT LOCK M8 2
25 P05491 BOLT 1" UNFx4½"" GR. V 1
26 P05492 NUT LOCK 1" UNF 1
27 P07361 GREASE NIPPLE 45° 2
28 P07543 PLASTIC END CAP 40x40 4
29 P07922 BUSH SPRUNG - Ø32xØ26x15 2
30 P08331 WASHER FLAT M24x2 30
31 P08833 SHIM COLLAR Ø45 1
32 P08866 BOLT M12x110 GR8.8 2
33 P09162 TOOLBOX LID 1
34 P10017 TOOLBOX BODY 1
35 P11156 SHIM KIT FOR Ø60mm ROD 1
36 P12358 CAPSCREW M8x60 GR10.9 2
37 P12610 BOLT M24x120 GR 10.9 STR 1
38 P12620 TOP PLATE 26
39 P12621 SPACER Ø36xØ16.5x31mm 52
40 P12783 LYNCH PIN CAT 0 26
41 P12810 NUT CASTLE M24 26
42 P12815 BOLT M24x185 STRUCTURAL GR 8.8 26
43 P14334 WING RH 1
44 P14405 6.7m TRACKROD 2
45 P14481 GANG ANGLING JACK 2
46 P14629 LATCH 1
47 P15429 TIE BAR JACK MOUNT 2
48 P15434 PIN - ROLL PIVOT 4
49 P15438 ANGLE GUIDE 2
50 P16816 BOLT M24x160 GR10.9 3
