7. Parts & Assembly
AS1601 FU LL ASSEMBLY
X-PR ESS 5.5m
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 AS1603 DRAWBAR ASSEMBLY - X-PRESS 1
2 AS1604 CHASSIS ASSEMBLY - X-PRESS 2004 1
3 AS1605 LIFT AXLE ASSEMBLY - X-PRESS 2004 1
4 AS1609 ROLL CARRIER ASSEMBLY RH 5.5m 1
5 AS1610 ROLL CARRIER ASSEMBLY LH 5.5m 1
6 AS1615 DISC FRAME ASSEMBLY RH 5.5m 1
7 AS1616 DISC FRAME ASSEMBLY LH 5.5m 1
8 AS1622 HYDRAULIC COMPONENTS X-PRESS 1
9 AS1628 DISC FRAME ADJUSTER ASSEMBLY - HYDRAULIC 2
10 AS1629 DISC FRAME ADJUSTER ASSEMBLY - MANUAL 2
11 P12720 MANUAL - X-PRESS 1
