Page 26
Revision
Comments
Part Description
Part No.
Ref.
NUT HEX FLANGE LOCK 3/4-10 PLT
803-181C
47.
MIDWAY ROD CLEVIS 3/4-16 UNF
810-491C
48.
Refer to "Rockshaft" for breakdown
3N40HD 10 BOLT HUB AND SPINDLE
196-460K
49.
SPRING COMP 1.88OD x .362W
807-143C
50.
SPRING COMP 1.4OD .162W 3LG
807-212C
51.
HHCS 1/4-28X3/8 GR5
802-300C
52.
HHCS 1-8X5 1/2 GR5
802-205C
53.
NUT HEX SIDE LOCK 1-8 PLT
803-316C
54.
S/N(1063TT-)
3N40 HD BLK SED CSTR VER SHAFT
196-979D
55.
S/N(1064TT+)
4 1/2 CASTER VERTICAL SHAFT
296-138D
55.
PIN COTTER 5/16 X 2 1/2
805-085C
56.
PIN 3/4 X 4 13/32 USEABLE
805-230C
57.
CYL REP 5X20X2 ROD (TIE)
810-500C
58.
WASHER FLAT 1 1/4 SAE PLT
804-039C
59.
HHCS 3/4-10X5 1/2 GR5
802-594C
60.
NUT LOCK 3/4-10 PLT
803-026C
61.
NUT HEX JAM 3/4-10 PLT
803-048C
62.
HHCS 1-8X3 GR5
802-368C
63.
NUT HEX JAM 1-8 PLT
803-030C
64.
HOSE LOOP 2 5/8 WITH TAB
160-018H
65.
NUT HEX 5/8-11 PLT
803-021C
66.
WASHER LOCK SPRING 5/8 PLT
804-022C
67.
HHCS 5/8-11X1 3/4 GR5
802-053C
68.
HHCS 5/8-11X5 GR5
802-062C
69.
PIN 3/8 X 3 USABLE LW/PIN
805-001C
70.
WASHER FLAT 3/4 SAE PLT
804-025C
71.
WASHER MACH 1.19 X .63 X 18GA
804-040C
72.
PIN COTTER 3/16 X 1 3/4 PLT
805-017C
73.
S/N(1064TT+)
4 1/2 PIVOT THRUST WASHER
296-139D
74.
S/N(1063TT-)
PIVOT THRUST WASHER
804-102C
74.
196-444P
- 26 -
04/10/13
Gauge Wheel (continued)
(Applies to 3N-4010HDA only)
