Great Plains P17897B Operator Manual - Manual (Page 125)

125 X-Press
Operating Instructions
7. Parts and Assembly
AS4199 ROLL UNIT RH - 6.6m - DDL600 - 150
ITEM PART NO DESCRIPTION QTY COMMENTS
1 AS4194 SCRAPER ASSEMBLY DDL150 21
2 P01834 BEARING SCJ 50 2
3 P02007 NUT LOCK M12 8
4 P02008 NUT LOCK M16 'TYPE T' 6
5 P02009 NUT LOCK M20 8
6 P02601 WASHER FLAT M12 8
7 P02602 WASHER FLAT M16 6
8 P02603 WASHER FLAT M20 8
9 P05030 SCREW M12x55 CSK GR10.9 8
10 P05617 SCREW M12x65 CSK GR10.9 8
11 P06802 BOLT U M16 GR8.8 190x117 3
12 P12758 STUB AXLE END WASHER Ø50 2
13 P12950 BOLT M12x35 SOCKET CAP 4
14 P13377 RETAINING PLATE 2
15 P15186 DD600 RING - 275 BORE 44
16 P15411 BOLT M20x80 GR10.9 CSK 8
17 P15638 1/8TH BSP GREASE NIPPLE 45° 2
18 P16163 15MM END SPACER RING 1
19 P16239 ROLL TUBE - 3285mm 1
20 P16371 END SPACER RING 20mm 1
21 P16373 END SPACER RING 10mm 1
22 P16678 DDL 600 SPACER 8X58MM 21
23 P16707 INTRNL SPACER 86X8M 22
24 P17831 PILLAR RH - FOR P01834 1
25 P17832 PILLAR LH - FOR P01834 1
26 P17838 SCRAPER RAIL RH - 3305mm 1
