Page 2: Lx™ 5

Vue™ I

Vue™ I i

Vue™ I I

Vue™ I i i

Vue™ I I I

Vue™ V i

Vue™ V I

• 6-channel DMX LED moonflower
• Blackout/static/strobe
• Individual control of red, green
and blue LEDs
• Built-in automated programs via
master/slave or DMX
• Built-in sound activated programs via
master/slave or DMX
• Linkable with Vue™ II and Vue™ VI
• Weight: 3.7lbs (1.7kg)
• Light source: 84 long life LEDs
(36 red, 24 green, 24 blue)

• 6-channel DMX LED moonflower
• Blackout/static/strobe
• Individual control of red, green
and blue LEDs
• Built-in automated programs via
master/slave or DMX
• Built-in sound activated programs via
master/slave or DMX
• Linkable with Vue™I and Vue™ VI
• Light source: 162 long life LEDs
(60 red, 36 green, 66 blue)

• 9-channel DMX LED moonflower
• Blackout/static/strobe
• Individual control of red, green
and blue LEDs within each cluster
(7 total)
• Built-in automated programs via
master/slave or DMX
• Built-in sound activated programs via
master/slave or DMX
• Light source: 469 long life LEDs
(280 red, 63 green, 126 blue)

• 6-channel DMX LED moonflower
• Blackout/static/strobe
• Individual control of red, green
and blue LEDs within each cluster
(3 total)
• Built-in automated programs via
master/slave or DMX
• Built-in sound activated programs via
master/slave or DMX
• Linkable with Vue™I and Vue™ II
• Light source: 400 long life LEDs
(252 red, 72 green, 72 blue)

Less
than 4lbs

Elan™

J-Five™

MiN™ Spot

MiN™ Wash

• 4-channel DMX LED effect light
• Blackout/static/strobe
• Individual control of red, green and
blue LEDs
• Built-in automated programs via
master/slave
• Built-in sound active programs via
master/slave
• Light source: 224 long life LEDs
(88 red, 48 green, 88 blue)

• Dual LED moonflower effect
• Dual rocker switches: 1 for LEDs,
1 for motors
- Sound activated
- Static (motors only)
- Automatic
• Additional power output: max 50
units @ 120V

(see manual for details)

• Light source: 112 long life LEDs
(16 red, 24 green,16 blue)

• DMX LED moving yoke spot
• 5 or 13-channel of DMX
• Pan: 540º / Tilt: 270º
• RGB color mixing
• Gobo wheel - 9 gobos + open
- Gobo wheel spin effect
• Built-in automated programs via
master/slave (fast and slow)
• Built-in sound activated programs via
master/slave
• Light weight: 8.3Lbs (3.8kg)
• Very compact: 6.8in x 6.8in x 9.8in
• Light source:
1 (14W RGB) long life LED

• DMX LED moving yoke color wash
• 5 or 13-channel of DMX
• Pan: 540º / Tilt: 270º
• RGB color mixing
• Built-in automated programs via
master/slave (fast and slow)
• Built-in sound activated programs
via master/slave
• Light weight: 8.3Lbs (3.8kg)
• Very compact: 6.8in x 6.8in x 9.8in
• Light source:
1 (14W RGB) long life LED

Lighting
Product
of the Year

Effect
Product
of the Year

LEDsplash™ 2

Hurricane™ 650

Ultimate HZ™

• 6-channel DMX LED wash light
• Blackout/static/dimmer/strobe
• Static colors and RGB color mixing
with or without DMX control
• Built-in automated programs via
master/slave or DMX
• Built-in sound activated programs via
master/slave or DMX
• High-power, 1W (350mA) LEDs
• Light source: 24 long life LEDs
(8 red, 8 green, 8 blue)

LX™ 5

LX™ 10

• LED moonflower effect
• Selectable functions: sound, rotating
• Additional power output: max 50 units
@ 120V (see manual for details)
• Light weight: 3.5lbs (1.6kg)
• Very compact: 8.8in x 5.3in x 7.5in
• Light source: 57 long life LEDs
(17 red, 24 green,16 blue)

• LED moonflower effect
• Mirror scans 180º
• Selectable functions: sound, rotating
• Additional power output: max 50 units
@ 120V (see manual for details)
• Light weight: 5lbs (2.3kg)
• Very compact: 15.5in x 5.3in x 8.5in
• Light source: 57 long life LEDs
(17 red, 24 green,16 blue)

• 450-watt heater
• Output: 1,500cfm
• 1 pint tank capacity
• Manual fog button
• Wired remote included

• 2-channel DMX-512 hazer
• Variable output angle
• 400-watt heater
• Output: 1,500cfm
• 1.6 quart tank capacity

Powerful 1W LEDs

Run 50 units on 1 circuit !!!

Don’t forget the fog !!!

Looks even better with fog !!!

The world’s
smallest
moving
yoke spot

Pint-sized
powerhouse.
