Great Plains 3000TT Rolling Harrow & Board Assembly Instructions User Manual
Page 9
4/20/2004
REF
DESCRIPTION
PART NO.
PART NO. 1200TT
2200TT
3000TT
4000TT
NO.
(KENT MFG)
(GP)
31 4' LEVELING BOARD
n/a
589-058D
4
5' LEVELING BOARD
n/a
589-043D
2
6
2
6' LEVELING BOARD
n/a
589-044D
2
2
2
32 36" MOUNTING TUBE
n/a
589-120H
0
0
0
4
48" MOUNTING TUBE
n/a
589-074H
0
2
6
2
56" MOUNTING TUBE
n/a
589-077H
2
2
0
2
30 LEVEL BOARD ARM
n/a
589-073H
4
8
12
16
4
REEL ARM
n/a
589-060H
4
8
12
16
6
ARM MOUNT BRKT
n/a
589-059H
4
8
12
16
7
CLEVIS BOLT, 3/4" x 22 1/4"
MC0078
575-516H
4
8
12
16
8
LONG SPRING
DA0056
807-224C
4
8
12
16
9
SHORT SPRING
PW0134
807-226C
4
8
12
16
12 EYE BOLT, 3/4 x 5 1/2 LONG
MC0048
802-768C
4
8
12
16
70 REAR STAND LEG
FC1606
560-196H
1
1
1
1
71 REAR STAND MOUNT BRACKET
PW0282
580-049H
1
1
1
1
72 3/4 X 4 1/2 PIN AND RETAINER
131272
805-081C
1
1
1
1
13 3/4 x 4 1/2 HEX BOLT
111272
802-192C
4
8
12
16
35 3/4 x 2 HEX BOLT
111232
802-064C
4
8
12
16
16 5/8 x 2 1/2 x 3 3/4 U-BOLT
UB0037
806-182C
8
16
24
32
44 5/8 x 3 x 4 1/2 U-BOLT
UB0029
806-183C
10
18
26
34
18 3/4 x 2 1/2 CLEVIS PIN
211040
805-140C
4
8
12
16
19 1/8 x 1 1/2" COTTER KEY
260224
805-225C
4
8
12
16
20 5/8 x 3 HEX BOLT
111048
802-059C
4
8
12
16
21 3/4" LOCKNUT
3112
803-026C
8
16
24
32
22 3/4" JAM NUT
3312
803-048C
12
24
36
48
24 3/4" FLAT WASHER
4012
804-024C
20
40
60
80
73 5/8" LOCK NUT
3110
803-024C
4
8
12
16
25 5/8" HEX NUT
3010
803-021C
36
68
100
132
26 5/8" LOCK WASHER
4110
804-022C
36
68
100
132
40 1/2" HEX NUT
3008
803-020C
8
16
24
32
41 1/2" LOCK WASHER
4108
804-015C
8
16
24
32
43 1/2" x 2 1/2" CARRIAGE BOLT
240840
802-571C
8
16
24
32
Board Width (Feet)
12.2
22.3
30.5
38.7
LEVELING BOARD FOR ROLLING HARROW
TURBOTILL FINISHING ATTACHMENTS
TurboTill Leveling Board.xls
