51 Flatliner 500
Operating Instructions
7. Parts & Assembly
AS2127 FLAT LIN ER 500
MAIN FR AME ASSEMBLY 4.2m H D
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 P12816 MAINFRAME - 4.2m HEAVY DUTY 1
2 P02484 LYNCH PIN CAT 2 4
3 P13130 PIN Ø50x235 CAT 4 LOW 2
4 P13129 PIN Ø45x190 CAT 4 UP 1
5 AS1266 TINE ASSEMBLY PROLIFT 7
6 P12643 STAND - FLATLINER 2
7 P12644 STAND MOUNTING 2
8 P12645 RETAINING PLATE 220x60 2
9 P02834 PIN - Ø25x170 2
10 P04675 RETAINING PLATE 12
11 P01274 PIN Ø25x115 2
12 P02608 WASHER FLAT M30 28
13 P00036 BOLT M30x180 GR. 8.8 2
14 P02011 NUT LOCK M30 2
15 P02604 WASHER FLAT M24 Ø50 7
16 P02010 NUT LOCK M24 7
17 P04536 BOLT M24x130 GR. 8.8 7
18 P02318 BOLT M16x120 GR. 8.8 7
19 P02038 WASHER SPRING M16 7
20 P01358 NUT PLAIN M16 7
21 P02486 R CLIP Ø7x170 3
22 P02008 NUT LOCK M16 4
23 P02602 WASHER FLAT M16 4
24 P06511 CLAMP - LONG 6
25 P06510 CLAMP - SHORT 6
26 P02598 WASHER SPRING M30 24
27 P00896 NUT PLAIN M30 24
28 P00983 BOLT M30x150 GR. 8.8 16
29 P00034 BOLT M30x160 GR. 8.8 8
