7. Parts & Assembly
MODEL
PART
NUMBER
3.0m
DTX TINE 400 W/DEPTH P16286 5
POINT P09148 5
WEARSHIN PROLIFT REVERSIBLE P12018 5
ROLL PIN Ø16x40 P02481 10
(OPTION) WING - PROLIFT LOW P09060 5
(STD) WING - PROLIFT 250mm P10392 5
(OPTION) WING - PROLIFT 350mm P10411 5
WEAR SHROUD P11181 5
BOLT M16x40 P00007 5
WASHER FLAT M16 P02602 5
NUT LOCK M16 P02008 5
POINT EP P15957 5
TINE - LD SHORT P15055 5
WING - LD P13812 5
CAPSCREW M12x40 GR10.9 P10367 5
NUT LOCK M12 P02007 5
BOLT M12x40 CSK SQ 8.8 P15809 5
NUT TOOTHED M12 P11275 10
BOLT M16x150 GR. 8.8 P01352 5
NUT LOCK M16 P02008 5
DISC BLADE Ø515x6 P11462 22
DISC ARM RH CT P16404 11
DISC ARM LH CT P16405 11
WASHER SPRING M12 P02037 110
BOLT M12x25 GR. 8.8 P11032 110
STEM - SCRAPER DDL600 CB P16473 14
SCRAPER - DDL600 P15448 14
BOLT M10x25 DOME SQ. P13942 14
NUT LOCK M10 P05534 14
RING DDL600 - 275mm BORE P15186 30
INTRNL SPACER 86X8M P16707 15
DDL 600 SPACER 107MM P16530 14
DTX
PART DESCRIPTION
SHEAR TRIP PROLIFT TINE ELEMENTS
ROLL SCRAPERS
DD RINGS
DISC HUBS
SHEAR TRIP LD TINE ELEMENTS
SHEAR BOLTS
