Great Plains Mfg., Inc.
Installation Instructions 5
10/10/2008 202-582M
Closeout
Refer to Figure 10
24. Replace gear box cover and install the two
3 ⁄
8
in
self-tapping screws .
25. Place the gear box handle so that the sight hole
is over the Drive Type plate, and secure handle with
1 ⁄
4
-28 bolt , washer and lock washer .
26. Return these instructions to the kit case. Store the
case for future use.
Using Reduced Seed Rate
The components installed reduce the population rate, for
Native Grass only, by 55%, which is an adjustment factor
of 0.45.
The Seed Rate Reduction kit does not affect the popula-
tion rates of:
• main seed box
• small seeds box
Not all Seed Rate manuals include both standard and
Reduced Rate charts.
Use your existing Seed Rate charts for native grass, and
apply the correction factor.
For Series I Native Grass Seeding
The chart rates, in pounds-per-acre, need to be adjusted
by multiplying by 0.45.
For Series II Native Grass Seeding
The chart rates, in cup-revolutions-per-acre, need to be
adjusted by multiplying by 0.45.
Maintenance
Re-check chain slack after first few hours or operation,
due to seating.
The installation of this kit requires no other changes to
the regular maintenance of the drill as specified in the
Operator’s Manual.
Figure 10
Install Gearbox Cover
25158
17
19
18
17
11
20
14
U
D
F
B
L
R
14
17
11
18 20 19
ReducedPoundsPerAcre ChartPoundsPerAcre 0.45
×
=
ReducedCupRevsPerAcre ChartCupRevsPerAcre 0.45
