Great Plains X-PresS 2006 Assembly Instructions - Manual (Page 47)

81 X-Press
Operating Instructions
7. Parts & Assembly
AS2265 H YD R AU LIC COMPON EN T LAYOU T
IT EM PART NO DESCRIPT ION QT Y COMMENT S
1 P00205 QUICK RELEASE MALE - ½" BSP 2
2 P07930 DOC VALVE VODL/SC12 1
3 P11021 VALVE FDC VDFR38-24 3/8" 1
4 P03687 DOWTY SEAL 3/8" BSP 16
5 P06641 ADAPTOR MALE - MALE 3/8"-3/8" BSP 9
6 P12769 ADAPTOR T SFOL 3/8" BSP 1
7 P14093 CYLINDER Ø100 x 570 C/W EYE BOTH ENDS 2
8 P00071 NIPPLE - GREASE 4
9 P11604 BANJO BOLT 3/8" 2
10 P11605 BANJO BLOCK 3/8" 2
11 P00774 SHUT OFF TAP ½" BSP 2
12 P02263 DOWTY SEAL ½" BSP 6
13 P14095 ADAPTOR MALE 1/2" - FEMALE 3/8" 2
14 P03686 ADAPTOR MALE - MALE ½"-3/8" BSP 4
