Figure 4 Installing the Hydraulic Hose Between the Control Valve and Winch

PART

DESCRIPTION

A

STEEL ELBOW 90.1 /
2FNPSMX3 / 8MNPT (1100625)

B

H12X150P (29363)

C

H12X80P(29371)

D

PIONEER COUPLER (9900047)
