Replacement Parts List
1 Foot cover
✛
SV611000AV 4
2 Large hose clamps SV611100AV 2
3 Glove SV611200AV 2
4 Lamp switch
✛
SV611300AV,
▲
1
5 Switch outlet
✛
SV611600AV,
▲
1
6 Power supply SV611800AV 1
7 Plastic hex nut
✛
SV612000AV,
●
1
8 Plastic feed through
✛
SV612100AV,
●
1
9 Door latch
✛
SV612200AV 2
10 Pipe clamp
✛
SV612300AV 2
11 Plastic plug SV612500AV 1
12 Small hose clamp
✧
2
13 1/4 in. hose end connector (cabinet inlet fitting)
❍
2
14 Washers (shown for placement only)
❇
—
15 Female fitting SV613100AV 1
16 1/4 in. I/M (M) NPT plug HF001300AV 1
17 Chain
■
—
18 Large rubber seal
◆
1
19 Vacuum sponge and paper filter
◆
1
20 Retaining ring SV613700AV 1
21 Lamp clip
✛
SV613800AV 2
22 Lamp
●
1
23 Knob
✛
SV614100AV 1
24 Cabinet filter SV614300AV 1
25 Filter housing SV614400AV 1
26 Parts tray
❒
1
27 Plastic open acorn nut
✛
SV615500AV,
●
1
28 1/4 in. air hose SV615400AV 1
29 Gun AT212000AV —
30 Plastic door cover
▼
3
31 Lamp switch box
▲
1
Warning decal DK765000AV
Other cabinet hardware not listed are standard hardware items which are available at local hardware stores
✛
Required 6 - 8 week lead time necessary for order
❇
Standard Hardware Item
— Not Available
REPLACEMENT PARTS KITS (Kits include necessary hardware)
●
Lamp kit SKS30001AV
▲
Lamp switch kit SKS30002AV
■
Chain kit SKS30003AV
◆
Vacuum filter kit SKS30004AV
❒
Parts tray kit SKS30005AV
▼
Plastic door cover (5) kit SKS30006AV
❍
1/4 in. hose end (2) kit SKS30007AV
✧
Small hose clamp (5) kit SKS30008AV
Carbon nozzle kit (not shown) MXS40003AV
Ceramic nozzle kit (not shown) MXS40002AV
Ref.
No. Description Part No. Qty.
For Replacement Parts or Technical Assistance,
Call 1-888-Maxus4U (1-888-629-8748)
Please provide following information: Address parts correspondence to:
-Model number Attn: Customer Service
-Date code (if any) 100 Production Drive
-Part descriptions and number as shown in parts list Harrison, OH 45030
