BURNER HEAT INPUT INJECTOR HEAT INPUT INJECTOR
HOTPLATE
Front left
HOTPLATE
Rear right
HOTPLATE
Front right
HOTPLATE
Rear left
GRILL
OVEN
3.0 kW
2.0 kW
1.0 kW
3.8 kW
2.5 kW
128
102
72
135
115
2.8 kW (205g/h)
1.8 kW (130g/h)
1.0 kW (75g/h)
3.4 kW (245g/h)
2.5 kW (180g/h)
82
65
50
2.0 kW 102 1.8 kW (130g/h) 65
91
75
TECHNICAL DATA
DIMENSIONS
Height 900mm
Width
500mm
Depth 600mm (excluding door handles)
GENERAL
Gas connection
Rp 1 /
2
( 1 /
2
” BSP female)
Pressure test point Grill injector
Gas rate adjustment None
Aeration adjustment None
Battery 1.5V Alkaline AA.
19
INSTALLATION INSTRUCTIONS
NATURAL GAS LPG
