Antenna System Crestron SRD-ANT-1LD-PAK
Specifications
Following are specifications for the SRD-ANT-1LD-PAK.
SRD-ANT-1LD-PAK Specifications
SPECIFICATION DETAILS
Antenna
Bandwidth
Gain
Polarization
Beam
width
Output connector
Wind resistance
2320 to 2345 MHz
12dBi (Typical)
Left hand circular
± 25°
F-female
Up to 100 MPH
Amplifier
Gain
Current
Consumption
Power passing
16 dB (Typical @ 4.5 VDC)
10 milliamps @ 4.5 VDC
Both directions
Environmental Temperature -40° to 150°F (-40° to 66°C)
Humidity 0% to 98% RH
(non-condensing)
Overall Dimensions
Antenna
Height
Width
Depth
Wall
Mount
Height
Width
Length
Amplifier
Height
Width
Depth
7.75 in (19.69 cm)
7.75 in (19.69 cm)
1.19 in (3.03 cm)
2
5.38 in (13.67 cm)
3.38 in (8.59 cm)
11.63 in (29.54 cm)
0.64 in (1.63 cm)
3.25 in (8.26 cm)
1.07 in (2.72 cm)
Weight 2.0 lbs (0.9 Kg)
Included Items
The items included in the SRD-ANT-1LD-PAK are listed below and illustrated on
the following page.
SRD-ANT-1LD-PAK Included Items
DESCRIPTION PART NUMBER QTY
Satellite Radio Antenna SRD-ANT-1 1
Wall Mount Bracket 2021597 1
Pole Mount Saddle 2021596 1
Mounting Screws and Hardware Package 4506257 1
Weather Boot 2021595 1
F-female to SMB-plug, 3 ft cable 2021515 1
In-line Amplifier SRD-AMP-1 1
2 • Antenna System: SRD-ANT-1LD-PAK Installation Guide – DOC. 6722A
