Tension Brakes/Air Cooled
P-1100-WC 1/12
Wichita Clutch 800-964-3262 109
ModEvo Model 300
* For single actuator operation torques for 300/1 are applicable.
Without Fan
2.41
2.68
3.35
4.02
4.56
5.09
5.63
(1.8)
(2.0)
(2.5)
(3.0)
(3.4)
(3.8)
(4.2)
With Electric Cooling Fan, 150 mm dia.
6.30
6.70
6.70
6.70
7.37
8.04
8.04
(4.7)
(5.0)
(5.0)
(5.0)
(5.5)
(6.0)
(6.0)
**For intermittent duty, consult the factory.
1 Minimum torques were calculated using a multiplier of 0.6 for LC times Standard.
2 LC - Low Coefficient based on 0.2 Coefficient of friction.
3 Standard based on 0.35 Coefficient of friction.
4 Max. speed is with standard brake disc. A high speed brake disc capable of 50% higher speed is also available. Heat Capacity
reduced by 10% when high speed disc is used.
5 Limit LC to 70% of heat capacity.
6 When selecting number of actuators, use a limit of 3.35 HP per actuator pair (2.5 kW per Actuator pair) for duty w/o fan and 3.75 HP per Actuator
pair (2.8 kW per Actuator pair) when fan cooled.
Note: Limit maximum operating temperatures of surfaces (rotor, friction pads, actuators, etc.) to 300°F or less.
Temperatures above 300°F may cause damage and failure of components. Failure to do so will void warranty.
Inertia
Speed
4
Heat Capacity for Effective
Rotating
Model
6
Max.
Cooling Speeds
Parts
Weight
Continuous Duty
**
HP(kW)
5
lb.ft.
2
lbs.(kg)
(kbm
2
)
50
100
200
300
400
500
600
RPM
RPM
RPM
RPM
RPM
RPM
RPM
RPM
Total
Rotating
300/1
1900
38.140
(17.3)
300/2
1900
39.904
2.966
(18.1)
29.883
300/4
1900
(0.125)
49.604
(13.6)
(22.5)
300/6
1900
59.525
(27.0)
300/8
1900
69.446
(31.5)
Model
Minimum Torques
Minimum (3 PSI) (0.2 Bars)
1
lb.ft.(Nm)
LC
2
Std
3
LC
2
Std
3
LC
2
Std
3
25% Actuators
60% Actuators
100 % Actuators
300/1
0.7
1.1
1.6
2.6
2.6
5.2
(0.9)
(1.5)
(2.2)
(3.6)
(3.6)
(7)
300/2*
1.6
2.6
3.7
6.2
6.2
10.3
(2.1)
(3.5)
(5)
(8.4)
(8.4)
(14)
300/4*
3.1
5.2
7.4
12.4
12.4
20.6
(4.2)
(7)
(10.1)
(16.8)
(16.8)
(28)
300/6*
4.5
7.7
11.1
18.5
18.5
30.9
(6.3)
(10.5)
(15.1)
(25.2)
(25.2)
(42)
300/8*
6.2
10.3
14.9
24.8
24.8
41.3
(8.4)
(14)
(20.2)
(33.6)
(33.6)
(56)
Maximum Torques
Maximum (87 PSI) (6 Bars)
lb.ft.(Nm)
300/1
19.8
34.9
47.4
83.6
79
139.4
(27)
(47.3)
(64.8)
(113.4)
(108)
(189)
300/2*
39.8
69.7
95.4
167.3
159
278.8
(54)
(94.5)
(129.6)
(226.8)
(216)
(378)
300/4*
79.5
139.4
190.8
334.6
318
557.6
(108)
(189)
(259.2)
(453.6)
(432)
(756)
300/6*
119.3
209.1
286.2
501.8
477
836.4
(162)
(283.5)
(388.8)
(680.4)
(648)
(1,134)
300/8*
159.3
278.8
382.2
669
637
1,115
(216)
(378)
(518.4)
(907.2)
(864)
(1,512)
ModEvo Tension Brakes
