I N D U S T R I A L C L U T C H P R O D U C T S
Model LKM
D
E
C
G
N
A
L
B
M
F
K
J
I
H
3/4"-NPT
ROTARY
AIR INLET
MOUNTING
PLATE ADAPTORS
AVAILABLE AS
AN OPTION
DOUBLE DISK LKM CLUTCH
LKM
G
H
N
Model
A
B
C
D
E
F
Min.-Max.
No.-Size
I
J
K
L
M
Min.-Max.
LKM-213
8.69
7.86
16.63
16.25
14.65
5.25
2-7/8 - 3-1/2
8-15/16
1
.44
1.50
.18
4
3-1/2 - 4-3/8
LKM-313
10.50
9.69
16.63
16.25
14.63
7.06
2-7/8 - 3-1/2
8-15/16
1
.44
1.50
.18
4
3-1/2 - 4-3/8
LKM-218
11.31
10.31
22.63
21.50
20.00
7.75
2-7/8 - 4-1/8
12 - 1-1/16
1
.56
1.38
.18
4
4-1/2 - 5-9/16
LKM-318
14.19
13.19
22.63
21.50
20.00
10.63
2-7/8 - 4-1/8
12 - 1-1/16
1
.56
1.38
.18
4
4-1/2 - 5-9/16
LKM-221
11.06
10.44
25.00
24.50
22.50
6.81
3-3/8 - 5-1/2
12 - 1-1/16
1
.31
2.19
.18
4
4-1/2 - 5-15/16
LKM-321
13.63
13.00
25.00
24.50
22.50
9.38
3-3/8 - 5-1/2
12 - 1-1/16
1
.31
2.19
.18
4
4-1/2 - 5-15/16
LKM-225
14.38
13.63
29.75
29.25
27.00
8.50
4-5/8 - 7-1/2
12 - 1-5/16
1-1/4
.78
3.31
.18
4
4-1/2 - 6
LKM-325
17.63
16.86
29.75
29.25
27.00
11.75
4-5/8 - 7-1/2
12 - 1-5/16
1-1/4
.78
3.31
.18
4
4-1/2 - 6
LKM-230
15.63
13.25
35.50
35.00
32.00
9.00
5-1/4 - 9-5/8
12 - 1-1/4
2
1.06
3.06
.25
4-5/8
5 - 8
LKM-330
18.94
16.56
35.50
35.00
32.00
12.25
5-1/4 - 9-5/8
12 - 1-1/4
2
1.06
3.06
.25
4-5/8
5 - 8
LKM-235
15.63
13.38
41.50
40.75
36.88
7.69
8 - 12
24 - 1-1/4
2
1.13
3.88
.25
3-7/8
6 - 9-1/16
LKM-335
18.06
15.81
41.50
40.75
36.88
10.13
8 - 12
24 - 1-1/4
2
1.13
3.88
.25
3-7/8
6 - 9-1/16
LKM-242
18.27
16.58
48.75
48.00
44.00
10.75
8 - 12
24 - 1-3/4
3
1.00
4.00
.25
3-7/8
6-1/2 - 9-1/16
LKM-342
22.13
20.44
48.75
48.00
44.00
14.63
8 - 12
24 - 1-3/4
3
1.00
4.00
.25
3-7/8
6-1/2 - 9-1/16
LKM-248
21.02
18.77
54.75
54.00
50.00
11.56
9-1/8 - 14
24 - 1-3/4
3
1.38
5.00
.25
2-3/4
10 - 14.50
LKM-348
25.50
23.25
54.75
54.00
50.00
16.00
9-1/8 - 14
24 - 1-3/4
3
1.38
5.00
.25
2-3/4
10 - 14.50
DIMENSIONAL DATA
All dimensions in inches
NOTES: 1.) Use certified drawing dimensions only for final layouts.
2.) DXF and IGES files available upon request.
3.) Dimensions subject to change without notice.
4.) Consult factory or refer to application information when selecting units.
