Model cbh, Cnc control punching head – Wichita Clutch CBH Clutch Brake User Manual
Page 6
73
I N D U S T R I A L C L U T C H P R O D U C T S
Model CBH
CNC CONTROL
PUNCHING HEAD
HYDRAULIC
POWER
UNIT
24VDC VALVE SIGNAL
MONITORS
POWER TO HPU
TDC MONITOR
BRAKE ON SIGNAL
CAM
MOUNTING BRACKET
MODEL CBH
CLUTCH-BRAKE
VALVE ASSEMBLY
SEAL DRAINS
RETURN OIL
ACTUATION OIL
COOLING OIL
TYPICAL TURRET PUNCH PRESS INSTALLATION
