EARSET CUSTOM FITTING
Wi AudioStream EL
24
Positioning The Microphone Capsule
The Wi Sure-Fit EL Series removable microphone capsule
is located at the tip of the boom. The key to maximizing the
sound quality is to locate the capsule as close as possible to
the mouth without touching the face.
1. Press the boom locking switch located on the bottom
of the Silicon ear mount.
2. Slide the boom shaft to position the MIC capsule
just behind the corner of your mouth when you
are smiling.
3. Release the locking switch when adjustment is complete.
• Placing the microphone too far forward
can result in breath-related pops.
• Use the windscreen outdoors.
