ATTACHING THE FINDER SCOPE
Loosen the finder bracket lock screw on the telescope’s finder bracket shoe. Attach the finder scope as
shown in the figure and tighten the finder bracket lock screw securely.
ACCESSORY CHART
You may need an eyepiece as sold separately. The telescope does not come with the eyepiece as
standard accessory unless you purchased a package.
VISUAL CONFIGURATION
Magnification of
the Telescope
When using an
eyepiece with
short focal length
(small number in
millimeters), the
image will be dim
and the range of
sharp focus will
be small. The
image will be
harder to see so
begin with an
eyepiece with
long focal length.
Dividing the focal
length of the
telescope by the
focal length of
the eyepiece
gives the
magnification.
Example: Calculating the eyepiece magnification of a telescope with 1035mm focal length.
Eyepiece Focal length of telescope Focal length of eyepiece Magnification
PL20mm 1800mm 20mm 90x
PL 5mm 1800mm
5mm 360x
