general transmitter specs.
Infrared
2.08 MHz & 2.54 MHz
Field Switchable
FM Wide-Band
32.768 KHz
± 25KHz
2500 Ft². 60 Ft. Transmission Carrier
Transmission Frequencies
Channel Switchable A or B
Modulation
Pilotone Frequency
Peak Deviation
Operating Range
16
owner’s manual
VoiceLink
VoiceLink Plus (IMA-100) specs.
Infrared FM
FM Wide-band
Ch. A: 2.08 MHz
850 nm
Ch. A: 32.768 KHz
50 µs
50 Hz, -13KHz, ± 3dB
›65 dB
‹1% @1KHz
± 10 KHz
± 25 KHz
Two, RCA
3.5mm with Gain Control, Front
Panel
Two Amplifiers, 10 Watts ea. (RMS)
20 Watts total (RMS)
4Ω
One Four Pin Phoenix Connectors
12VDC / 0.6A / 7.2W
5" W x 1" H x 4 ½ " D
1 lb.
ABS Receiver Input
Modulation
Reception Frequencies
Infrared Wavelength
Tone Signal
De-emphasis
Frequency Response
S/N Ratio
THD
Nominal Deviation
Maximum Deviation
External Sensor Input
Aux Input
Output Power
Output Impedance
Output Connection
Power Supply
Dimensions
Weight
Enclosure
power supply (AC-15) specs.
Regulated Switching Power Supply
100–240 volts AC, 47–63Hz
12.0 volts DC, 2.0A
24 watts Max. Type
Input Voltage
Output Voltage
Power Output
