3
CR Series Woodburning Fireplaces
20001316
325
CR Specs
3/3/99 djt
Rough
Opening
Depth
22³⁄₄"
(578mm)
22"
(559mm)
10"
(254mm)
³⁄₄ " (19mm)
⁷⁄₁₆ " (11mm)
29¹⁄₄" (743mm)
11 " Dia.
(279mm)
1" Typ.
(25mm)
9⁷⁄₈"
(251mm) 6"
(159mm)
19⁹⁄₁₆"
(497mm)
21⁷⁄₁₆"
(545mm)
6³⁄₄ "
(172mm)
36" (914mm)
40¹⁄₈" (1019mm)
41¹⁄₂ "
(1054mm)
Gas Line
Access
9¹⁄₂"
(241mm)
8"
(203mm)
7"
(178mm)
14¹⁄₄"
(362mm)
4" Dia.
Outside
Air Collar
Rough
Opening
Height
CR36R/L Series Woodburning Fireplace
Fig. 1 CR36R/L Series specifications and framing.
(CR36R Shown)
25¹⁄₂" (648 mm) 25¹⁄₂" (648 mm)
32³⁄₈" (822 mm)
15⁵⁄₈"
(397 mm)
32³⁄₈" (822 mm)
15⁵⁄₈"
(397 mm)
CR36L CR36R
FP1538
CR Hearth size
10/04 djt
FP1538
Fig. 1a CR36R/L hearth dimensions.
